AIT Semiconductor A3085AM8VR – TR-3521-D

Get the high-quality AIT Semiconductor A3085AM8VR at the best price in India.

The A3085A is a half-duplex RS-485 transceiver with ±15kV IEC 61000-4-2 contact ESD protection. This device contains one driver and one receiver. The A3085A includes fail-safe circuitry, which guarantees a logic-high receiver output when the receiver inputs are open or shorted. This means that the receiver output will be logic high even if all transmitters on a terminated bus are disabled. The A3085A features reduced slew-rate driver that minimizes EMI and reduces reflections caused by improperly terminated cables, allowing error-free data transmission up to 500kbps.

AIT Semiconductor A3085AM8VR Specifications:-
+3.3V or +5V Operation
True Fail-Safe Receiver
Maximum Data Rate: 500kbps (VCC=5V) 250kbps (VCC=3.3V)
Allow Up to 256 Transceivers on the Bus
I/O Pins ESD Protection: ±15kV IEC 61000-4-2, Contact Discharge
Available in SOP8 package

Explore all the Latest Products of AIT Semiconductor
